Solar Battery

Deep Cycle Tubular Plate Battery

Technical Specifications
Capacity Weight & Dimension. Cell Type HPD 20T HPD 30T HPD 40T HPD 55T HPD 80T HPD 100T HPD 130T
Capacity in Ampere Hours at 25°C 20 Hr.(C20) 24 35 44 65 90 115 140
10 Hr.(C10) 22 30 40 55 80 100 130
5 Hr.(C5) 18.7 25.5 34 46.75 68 85 110.5
Discharge current in Ampere 20 1.2 1.75 2.2 3.25 4.5 5.75 7.0
10 2.2 3.0 4.0 5.5 8.0 10.0 13.0
5 3.74 5.1 6.8 9.35 13.6 17 22.1
External dimension of Cell(mm) Length(mm) 240 300 254 386 495 502 510
Width(mm) 125 170 223 178 182 220 270
Height with terminal(mm) 215 238 243 250 250 245 255
Approx.weight of Cell(kg) Dry 6.75 9.3 11.11 16.55 22.60 28.45 34.91
Wet 10.75 17.10 20.73 26.90 36.53 42.60 54.5
Approx.weight of Electrolyte (kg) Wet 4 7.8 9.62 10.35 13.93 14.15 19.59
No.of Pillars per Cell 2 2 2 2 2 2 2
Container Type NS-60 N-70 N60NS-100 N-100 N-120 N-150 N-200
Performance
Characteristics
Charging Efficiency
(Up to 60% state of charge) 97% Life-cycle
80% depth of discharge 1200 cycles
50% depth of discharge 2400 cycles
20% depth of discharge 3600 cycles
